Maxsun Challenger H510M-H V3 DDR4 H470 Intel LGA1200 Micro-ATX Motherboard – 10th/11th Gen Support | Tech Moon BD
Original price was: 9,000.00৳ .8,500.00৳ Current price is: 8,500.00৳ .
Key Features:
- Intel H470 Chipset – Supports Intel 10th & 11th Gen Core, Pentium & Celeron CPUs on LGA1200 socket)
- DDR4 Dual-Channel Memory up to 64 GB (3200 MHz OC) with Intel XMP 2.0
- PCIe 3.0 x16 & PCIe 3.0 x1 expansion slots
- M.2 PCIe 3.0 x4 + 3 × SATA 6 Gb/s storage with RAID 0/1/5/10 support
- Video outputs: HDMI (4K@30 Hz) & VGA
- Realtek 1G LAN & Realtek ALC897 5.1-Channel HD Audio
- USB 3.2 Gen1 + USB 2.0 for peripherals
- Micro-ATX form factor for compact builds (~225 × 180 mm)
The Maxsun Challenger H510M-H V3 DDR4 H470 Chipset Motherboard is a reliable and affordable choice for building Intel-based PCs in Bangladesh. Designed for 10th and 11th Generation Intel CPUs with the LGA1200 socket, this board offers essential features like DDR4 memory support up to 64 GB, NVMe M.2 storage, HDMI 4K output, and fast wired networking — perfect for everyday computing, office systems, multimedia rigs, and budget gaming builds. Available at Tech Moon BD with genuine warranty and nationwide delivery.
Specification :
| Feature | Details |
| Brand | Maxsun |
| Model | Challenger H510M-H V3 |
| Chipset | Intel H470 |
| CPU Socket | Intel LGA1200 — 10th & 11th Gen Core/Pentium/Celeron |
| Memory Type | DDR4 Dual-Channel |
| Memory Slots | 2 × DIMM |
| Max Memory | Up to 64 GB (DDR4-3200 OC) |
| PCIe Slots | 1 × PCIe 3.0 ×16, 1 × PCIe 3.0 ×1 |
| Storage | 1 × M.2 PCIe 3.0 x4, 3 × SATA 6 Gb/s (RAID 0/1/5/10) |
| Video Outputs | HDMI (4K @30 Hz), VGA |
| LAN | Realtek RTL8111H 1G Ethernet |
| Audio | Realtek ALC897 5.1-Channel HD Audio |
| USB | USB 3.2 Gen1 + USB 2.0 (Rear + Front) |
| Form Factor | Micro-ATX (225 × 180 mm) |
| OS Support | Windows 10 / Windows 11 (64-bit) |
| Warranty | 3 Years |
Description:
The Maxsun Challenger H510M-H V3 DDR4 H470 Chipset Motherboard is a versatile and performance-balanced Micro-ATX board perfect for users in Bangladesh building Intel systems with 10th or 11th Generation Core, Pentium, or Celeron processors. Featuring the Intel H470 chipset and LGA1200 socket, it supports modern CPU technologies while maintaining cost-effective pricing and reliable performance.
Memory is powered by dual DDR4 DIMM slots, supporting up to 64 GB of high-speed RAM with Intel XMP 2.0 overclocking potential, enabling smoother multitasking and responsiveness across applications. For storage, the board offers one M.2 PCIe 3.0 x4 slot for ultra-fast NVMe SSDs and three SATA 6 Gb/s ports with RAID support, giving flexibility for both high-speed and large-capacity drives.
Graphics outputs include HDMI (up to 4K @30 Hz) and VGA, making it compatible with a variety of monitors when combined with CPUs with integrated graphics. Expansion is supported through PCIe 3.0 x16 for discrete graphics and a PCIe 3.0 x1 slot for additional cards. Networking and audio are handled by Realtek 1G LAN and Realtek ALC897 5.1-Channel HD Audio, providing solid connectivity for gaming, streaming, and entertainment.
USB connectivity includes multiple USB 3.2 Gen1 and USB 2.0 ports ready for peripherals, storage drives, and accessories. Designed in the compact Micro-ATX form factor, it fits a wide range of cases without compromising on essential features. Whether you’re building a budget gaming PC, a home office computer, or a multimedia center, the Maxsun Challenger H510M-H V3 offers a dependable base at a competitive price — available now at Tech Moon BD with local warranty and support.
Question & Answer (Q&A):
Q1: Which CPUs are supported?
Supports Intel 10th & 11th Gen Core, Pentium Gold, and Celeron processors on LGA1200.
Q2: How much RAM can this motherboard support?
Up to 64 GB DDR4 with dual-channel support and Intel XMP tuning.
Q3: Does it support NVMe SSDs?
Yes — includes one M.2 PCIe 3.0 x4 slot for NVMe SSDs.
Q4: What video outputs does it offer?
It offers HDMI and VGA ports for integrated graphics displays.
Q5: Does it support RAID storage?
Yes — SATA RAID modes 0, 1, 5, and 10 are supported.
