Maxsun B760M Gaming ACE (Wi-Fi 6E) DDR5 Intel B760 Micro-ATX Motherboard – 12th/13th/14th Gen | Tech Moon BD
Original price was: 17,500.00৳ .15,500.00৳ Current price is: 15,500.00৳ .
Key Features :
- Intel B760 Chipset – Supports Intel 12th/13th/14th Gen LGA1700 CPUs
- DDR5 Dual-Channel Memory up to 96 GB (OC ready)
- Wi-Fi 6E (AX211) + Bluetooth 5.3 for fast wireless connectivity
- Realtek 2.5G LAN for reliable wired internet
- 3 × M.2 Slots + 4 × SATA 6 Gb/s storage support
- HDMI + DisplayPort outputs for integrated graphics support
- Realtek ALC897 7.1-Channel HD Audio
- Micro-ATX form factor ideal for compact gaming builds
The Maxsun B760M Gaming ACE (Wi-Fi 6E) DDR5 Intel Motherboard is a feature-rich gaming motherboard built on the Intel B760 chipset, designed to support Intel 12th, 13th, and 14th Gen processors on the LGA1700 socket. With high-speed DDR5 memory support, Wi-Fi 6E wireless, multiple M.2 storage options, and robust networking, this board delivers excellent performance and connectivity for gaming rigs, productivity PCs, and everyday builds in Bangladesh — available at Tech Moon BD.
Specification:
| Feature | Details |
| Brand | Maxsun |
| Model | B760M Gaming ACE (Wi-Fi 6E) |
| Chipset | Intel B760 |
| CPU Socket | LGA1700 – Supports Intel 12th/13th/14th Gen CPUs |
| Form Factor | Micro-ATX (~225 × 195 mm) |
| Memory Type | DDR5 Dual-Channel |
| Memory Slots | 2 × DIMM |
| Max Memory | Up to 96 GB (4800/5600/6400 MHz OC+) |
| PCIe Slots | 1 × PCIe 4.0 x16, 1 × PCIe 3.0 x1 |
| Storage | 2 × M.2 PCIe x4, 4 × SATA 6 Gb/s |
| Video Outputs | 1 × HDMI, 1 × DisplayPort |
| LAN | Realtek 8125 2.5G Ethernet |
| Wireless | Wi-Fi 6E + Bluetooth 5.3 (Intel AX211) |
| Audio | Realtek ALC897 7.1-Channel HD Audio |
| USB Ports | Multiple USB 3.2 & USB 2.0 Rear + Header support |
| RAID Support | RAID 0/1/5/10 (SATA) |
| OS Support | Windows 10/11, Linux 64-bit |
| Warranty | 3 Years |
Description:
The Maxsun B760M Gaming ACE (Wi-Fi 6E) DDR5 Intel Motherboard is crafted for gamers, creators, and performance-centric PC builders in Bangladesh who demand modern connectivity and expansion in a compact Micro-ATX form factor. Powered by the Intel B760 chipset, it supports the latest Intel 12th, 13th, and 14th Gen processors via the LGA1700 socket, delivering a strong foundation for both gaming and productivity builds.
Featuring dual-channel DDR5 memory support up to 96 GB, this board allows high-speed performance with OC-capable profiles (e.g., DDR5-6400+), improving responsiveness in heavy workloads and gaming. Storage versatility is covered with two high-speed M.2 PCIe x4 slots and four SATA 6 Gb/s ports, enabling fast NVMe SSDs for your OS and games alongside larger SATA drives for storage.
Connectivity is next-gen ready with Wi-Fi 6E and Bluetooth 5.3 for low-latency wireless networking, while Realtek 2.5G Ethernet offers stable wired speeds — ideal for online gaming and large file transfers. Display options include HDMI and DisplayPort, supporting integrated graphics from compatible Intel CPUs. Audio is handled by Realtek ALC897 codec, delivering rich, immersive sound for games and multimedia.
The rear I/O panel and headers bring a strong selection of USB 3.2 Gen 2×2 Type-C, USB 3.2 Gen 2 Type-A, and multiple USB 3.2 Gen 1/USB 2.0 ports for peripherals and high-speed accessories. Additional features like RAID support, debug LEDs, and comprehensive BIOS tuning tools make this an excellent choice for both enthusiasts and everyday builders. With robust features and reliable performance, the Maxsun B760M Gaming ACE stands out as a great Micro-ATX motherboard available at Tech Moon BD.
Question & Answer (Q&A):
Q1: Which Intel CPUs are supported?
Supports Intel 12th, 13th, and 14th Gen processors on the LGA1700 socket.
Q2: What DDR5 memory does it support?
Up to 96 GB DDR5 with OC profiles like 4800/5600/6400 MHz+.
Q3: Does it include wireless connectivity?
Yes — it features Wi-Fi 6E and Bluetooth 5.3 for fast wireless networking.
Q4: How many M.2 SSD slots are included?
It has two M.2 PCIe x4 slots for NVMe SSDs.
Q5: Is this motherboard good for gaming?
Yes — with DDR5 memory, fast networking, and multiple storage options, it’s excellent for gaming and performance PCs.
